TRENDnet User’s Guide

Cover Page



© Copyright 2018 TRENDnet. All Rights Reserved.


TRENDnet User’s Guide
Table of Contents
a
Thank you for purchasing your new TRENDnet Web
Smart Switch!



Please note: The scope of this user's guide encompasses multiple
products with varying features. Images, artwork, and other specificities
including port count, interfaces etc. may not be identical to the model
you purchased. Please consult the specific model specifications for your
unit for a full list of supported features.



Please ensure your switch’s firmware version is V2.10.010 or newer for
Layer 2+ management features. See the Firmware Upgrade section in
this document for additional information regarding the firmware upgrade
procedure.



Contents
Web Smart Switch Series Product Overview .................................... 1
TEG-082WS Overview .................................................................................................... 1
Package Contents ................................................................................................ 1
TEG-082WS Hardware Features .......................................................................... 1
TEG-204WS Overview .................................................................................................... 3
Package Contents ................................................................................................ 3
TEG-204WS Hardware Features .......................................................................... 3
TEG-284WS Overview .................................................................................................... 5
Package Contents ................................................................................................ 5
TEG-284WS Hardware Features .......................................................................... 5
TEG-524WS Overview .................................................................................................... 7
Package Contents ................................................................................................ 7
TEG-524WS Hardware Features .......................................................................... 7
Switch Installation .......................................................................... 9
Desktop Hardware Installation ...................................................................................... 9
Rack Mount Hardware Installation ................................................................................ 9
Basic IP Configuration .................................................................................................. 10
Connect additional devices to your switch .................................................................. 13
Accessing switch management interfaces ...................................... 14
Access your switch management page........................................................................ 14
Dashboard ................................................................................................................... 14
View your switch status information ................................................................. 14
Switch View ................................................................................................................. 16
View your switch status information ................................................................. 16
Real-time Statistics ...................................................................................................... 16
View your switch status information ................................................................. 16
System .......................................................................................... 17

Produktspecifikationer

Varumärke:	Trendnet
Kategori:	brytare
Modell:	TEG-082WS
Vikt:	1500 g
Bredd:	280 mm
Djup:	180 mm
Höjd:	44 mm
LED-indikatorer:	Ja
Certifiering:	CE, FCC
Kompatibla operativsystem:	Windows 8.1, 8, 7, Vista, XP, Windows 2003/2008 Server
Rackmontering:	Ja
Medeltid mellan fel (MTBF):	1054337 h
Antal VLAN:	256
Genomströmning:	11.9 Mpps
Portspegling:	Ja
Full duplex:	Ja
DHCP-funktioner:	DHCP server, DHCP client
Antal Combo SFP-portar:	2
Head-of-line (HOL) blockering:	Ja
Produktens färg:	Svart
Strömförsörjning via Ethernet (PoE) stöd:	Nej
Temperatur vid drift:	0 - 45 ° C
Intervall för relativ operativ luftfuktighet:	0 - 90 %
VLAN-stöd:	Ja
AC-inspänning:	100 - 240 V
Kryptering/säkerhet:	802.1x RADIUS, HTTPS
Växelström Frekvens:	50 - 60 hz
Webbaserad adminstraion:	Ja
Lednings Protokoll:	HTTP/HTTPS (SSL v2/3 TLS), SNMP v1/v2c/v3
Kommunikationsstandarder:	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
Stöd för garanterad tjänstekvalitet (QoS):	Ja
IGMP-snooping:	Ja
Multicast-stöd:	Ja
Adresstabellstorlek:	16000 poster
Jumbo Frames stöd:	Ja
Switch kapacitet:	16 Gbit/s
STP (Spanning Tree Protocol):	Ja
10G stöd:	Nej
Antal grundläggande RJ-45 Ethernet-portar:	8
Typ av grundläggande RJ-45 Ethernet-portar:	Gigabit Ethernet (10/100/1000)
Switch typ:	hanterad
Länkaggregering:	Ja
MIB stödd:	MIB, MIB-II
Antal Gigabit Ethernet (koppar)-portar:	8
Koppar Ethernet-kablar teknik:	1000BASE-T, 100BASE-TX, 10BASE-T
