Symbols

WARNINGS – To help avoid personal injury

Important Notes/Cautions – from the factory

Sanitation Requirements

1.Connectawaterlinefromyourfacilitytothe1/4”arewaterinletttingofthevalve,behindthemachine.Watervolumegoingtothe

machineshouldbestable.Usetubingsizedsufcientlytoprovideaminimumowrateofonegallonperminute.

2.Plugthepowercordintoanelectricaloutletratedat20A.

3.Switchonthetoggleswitch,behindtheunit,thatrunspowertothecomponentsinthemachine.ThedisplaywindowandStop/Wash

lightonthefrontdoorwillactivateandtheheatingtankwillstarttoll.

4.Waterintheheatingtankwillrequireabout½hourtoreachoperatingtemperature(factorysettingof190°F).AtthistimetheReady

lightwillappear.

5.Removeandllthecanisterswithpowderedcappuccinomixes.

FOR THE LATEST SPECIFICATIONS AND INFORMATION GO TO WWW.WILBURCURTIS.COM

Thisapplianceisdesignedforcommercialuse.Anyservicingotherthancleaningandmaintenanceshouldbeperformedbyanautho-

rizedWilburCurtisservicecenter.

•DoNOTimmersetheunitinwateroranyotherliquid

•Toreducetheriskofreorelectricshock,doNOTopentoppanel.Nouserserviceablepartsinside.Repairshouldbedone

onlybyauthorizedservicepersonnel.

•Keephandsandotheritemsawayfromhotpartsofunitduringoperation.

•Nevercleanwithscouringpowdersorharshimplements.

Your Curtis CAFE System is Factory Pre-Set and Ready to Go… Right from the Carton.

FollowingaretheFactorySettingsforyourPrimoCappuccinoBeverageSystem:

•TankTemperature=190°F•FlavorControls=Setat50%•DispensingModeSetforManualDispensing

Generallytherewillneverbeareasontochangeyourprogramming.However,shouldyouneedtomakeslightadjustmentstomeet

yourdispensingneeds,programminginstructionsareprovidedlaterinthismanual.

SystemRequirements:

•WaterSource20–90PSI(MinimumFlowRateof1GPM)

•Electrical:Seeattachedschematicforstandardmodelorvisitwww.wilburcurtis.comforyourmodel.

Equipmenttobeinstalledtocomplywithapplicablefederal,state,orlocalplumbing/electricalcodeshavingjurisdiction.

SETUP STEPS

Theunitshouldbelevel(lefttorightandfronttoback),locatedonasolidcountertop.Connectawaterlinefromthewaterltertothe

brewer.NOTE:Sometypeofwaterltrationdevicemustbeusedtomaintainatrouble-freeoperation.(Inareaswithextremelyhardwa-

ter,wesuggestthatasedimentaryandtaste&odorlterbeinstalled.)Thiswillprolongthelifeofyourdispensingsystemandenhance

cappuccinoproductquality.

NSFInternationalrequiresthefollowingwaterconnection:

1.Aquickdisconnectoradditionalcoiledtubing(atleast2xthedepthoftheunit)isrequiredsothattheunitcanbemovedfor

cleaning.

2.Thisunitmustbeinstalledwithadequateback-owprotectiontocomplywithapplicablefederal,stateandlocalcodes.

3.Waterpipeconnectionsandxturesdirectlyconnectedtoapotablewatersupplyshallbesized,installedandmaintainedin

accordancewithfederal,state,andlocalcodes.

FILL CANISTERS DAILY

1.Openthefrontdoortoaccessthecoffeecanisters.

2.Thecanistersmustberemovedfromtheunitforlling.Turntheproductdelivery

elbowsupward.

3.Repositionthecanistersonthemachine,turningtheproductdeliveryelbowsdown-

wardandaligningthegearsocketwiththemotorshaft.

Important Safeguards & Symbols

CAUTION: DONOT

connect this unit to hot

water.Theinletvalveis

notratedforhotwater.

CAUTION: Please use

thissetupprocedure

beforeattemptingtouse

thisappliance.Failuretofollowthe

instructionscanresultininjuryorthe

voidingofthewarranty.

WARNINGHOTLIQUID,

Scaldingmayoccur.

Avoidsplashing.

Models Included

wCAFEPC1

wCAFEPC1WITHLIGHTBOX

wCAFEPC2

wCAFEPC2WITHLIGHTBOX

wCAFEPC3

wCAFEPC3ICEDCAPPUCCINO

wCAFEPC3WITHLIGHTBOX

wCAFEPC4

wCAFEPC4WITHLIGHTBOX

OPERATING INSTRUCTIONS

1.Chooseaavor.Placeyourcupunderthespoutbeneaththedesiredavor.

2.Pushandholdthedispensingbuttonforthisavor.

3.Releasethebuttonwhenthecupis¾full.

W C CilbururtisompanynC, i.

ServiceManual–CAFEPC

ISO9001:2008REGISTERED

WILBURCURTISCO.,INC.

6913WestAccoStreet

Montebello,CA90640-5403

Forthelatestinformationgoto

www.wilburcurtis.com

Tel:800-421-6150

Fax:323-837-2410
