F indoutmore
ontheweb.
WILBURCURTIS.COM
1
F indoutmore
ontheweb.
WILBURCURTIS.COM
WILBUR CURTIS COMPANY
Montebello, CA 90640
Models Included
ILGD
TL-ILGD
this setup procedure
before attempting to use
this grinder. Failure to follow the
instructions can result in injury or the
WARNING TO AVOID
SCALDING, Do not
remove brewcone whil
brew light is ashing.
ISO 9001 REGISTERED
C
Service Manual – Digital InterLock Coffee Grinders
For the Latest speciFications and inFormation go to www.wiLburcurtis.com
This appliance is designed for commercial use. Any servicing other than cleaning and maintenance should be performed by an autho-
rized Wilbur Curtis service center.
•DoNOTimmersetheunitinwateroranyotherliquid
•Toreducetheriskofreorelectricshock,doNOTopentoppanel.Nouserserviceablepartsinside.Repairshouldbedone
only by authorized service personnel.
•Keephandsandotheritemsawayfromhotpartsofunitduringoperation.
•Nevercleanwithscouringpowdersorharshimplements.
Important Safeguards/Conventions
Conventions
WARNINGS–TohelpavoidpersonalinjuryImportantNotes/Cautions–fromthefactory
QUICKSTART&SETUP
SETUP
1.Installthegrinderonarm,levelbaseinalocationwhereitcanbeconnectedtoagroundedelectricaloutletof120VAC,ratedat15
amps.
2.Testtheunitbyrunningsomewholebeancoffeethroughthegrinder.Ifanyproblemsareencountered,refertothetroubleshooting
sectioncompleteatwww.wilburcurtis.comorcallTechnicalSupportat800-995-0417.
CONNECTINGTHEINTERLOCKGRINDER
1.TurnbothunitsOFF.
2.PlacethegrindercloseenoughtothebrewersoittheInterLockcablewillreachthebrewer.
3.Locatethejack,labeledCLASS2WIRINGONLY,onthebackofthebrewer.PlugintheInterLockcabelfromthegrinder.
4.TurnbothunitsON.Interlockingiscomplete.
INTERLOCKOPERATINGINSTRUCTIONS
1.Openthedoorontopofthegrinderandllwithfreshwholebeancoffee.Closethetopdoor.
2.PlaceanemptySatelliteonthewarmerdeckofthebrewerandpreheatitbyswitchingonwarmer.
3.Placeanewpaperlterintothebrewcone.
4.Insertthebrewconeintothebasketholderarmsonthegrinder.
5.Presstheappropriategrindswitch(SMALL,MEDIUMorLARGE).
6.Allowthegrindmotortocompletelystopbeforeremovingthebrewcone.Thebrew
selectionisnow“Locked”inatthebrewerandisindicatedbytheashinglightonthe
InterLockbrewer.
7.Transferthelledbrewconetothebrewerandpresstheashingbrewbutton.
Brewcycleiscompletewhenthebrewlightstopsashing.
ADJUSTINGTHEGRINDS
1.Emptyhopperofcoffeebeans.Rungrindertocleargrindingburrsofcoffee.
2.Openhousingcovertolocateadjustmentscrew(8)andlocknut(7).Loosenlocknut.
3.Runmotorduringadjustment.Turningadjustmentscrewclockwisewillresultinaner
grind(if,whileturning,youhearthegrindingburrsstartingtotouch,immediately,back
off1/8thturn).Turningcounterclockwisewillproduceacoarsergrind.
4.Withascrewdriverholdingtheadjustmentscrewinplace,tightenthelocknut.
5.Runsomecoffeebeansthroughthemachinetocheckthegrindadjustment.
6.Replacefrontcoveronmachine.
*Thisadjustmentmaychangetheamountofgroundcoffeedispensed.
CHANGINGABROKENSHEARDISK
1.Unplugthepowercord.
2.Emptythehopperofbeans.
3.Takeoutthethumbscrews(10)toremovethegrindcap(6).
4.Pulloutthegrindingburr/feedwormassembly(2).Theinnerhalfofthegrindingburrset
willremaininthehousing.
5.Separatetheshearcap(5)andsheardrive(3).Thesnappedsheardisk(4)shouldfall
out of it’s slot on the shear drive.
6.Inspectandcleanhousing(1)ofanycoffeeordebris.Especiallylookforanythingthatmayhavebrokenthesheardisk.
7.Re-insertthefeedwormandgrindingburrontothemotorshaft.
8.Pushsheardrivethroughburr/feedwormassemblyandalignlargeslotwithtongueonthemotorshaft.
9.Rotateburr/feedwormassemblytoalignslotwithnarrowslotonsheardrive.
10.Insertanewsheardiskintoslot.Coverwiththeshearcap.
11.Replacegrindcapandthumbscrews.
W C C, i.ilbururtisompanynC
