AXADCT-4AXADCT-4

INSTALLATION INSTRUCTIONSINSTALLATIONINSTRUCTIONS

AXADCT-4AXADCT-4

INSTALLATIONINSTRUCTIONSINSTALLATIONINSTRUCTIONS

REV. 4/27/20REV. 4/27/20

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

REV. 4/27/20REV. 4/27/20

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Integrate • AxxessInterfaces.comIntegrate • AxxessInterfaces.com

Wire Color & Function: The audio and power input wire colors are an EIA standard for car

stereo applications as follows.

INPUT HARNESS POWER HARNESS

WhiteLEFT Front (+) Input YellowBATTERY +12V Input

White/BlackLEFT Front (-) Input Black POWER (-) GROUND Input

GrayRIGHT Front + Input Blue REMOTE +12V Output

Gray/BlackRIGHT Front (-) Input Black/White Reference Ground(-)

GreenLEFT Rear (+) Input

Green/BlackLEFT Rear (-) Input

PurpleRIGHT Rear (+) Input

Purple/BlackRIGHT Rear (-) Input

OUTPUT HARNESS

WhiteLEFT Front (+) Output Green LEFT Rear (+) Output

White/BlackLEFT Front (-) Output Green/Black LEFT Rear (-) Output

GrayRIGHT Front + Output Purple RIGHT Rear (+) Output

Gray/BlackRIGHT Front (-) Output Purple/Black RIGHT Rear (-) Output

Note: Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXADCT-4. The same goes for the negative audio

wires. Failure to do this will result in poor bass response and low quality audio.

Adjusting the AXADCT-4 for maximum performance: After completing all of the necessary

connections, turn the AXADCT-4 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and adjust the main volume

control on the stereo to approximately 3/4 maximum volume. Select one of the adjustment

pots on the AXADCT-4 and turn it slowly clockwise until you notice audio distortion and then

stop. Turn the remaining pots to the same position as the previously adjusted pot. The audio

set-up of the AXADCT-4 is now complete and ready to be enjoyed.

Wire Color & Function:The audio and power input wire colors are an EIA standard for car

stereo applications as follows.

INPUT HARNESS POWER HARNESS

WhiteLEFT Front (+) Input YellowBATTERY +12V Input

White/BlackLEFT Front (-) Input BlackPOWER (-) GROUND Input

GrayRIGHT Front + Input BlueREMOTE +12V Output

Gray/BlackRIGHT Front (-) Input Black/WhiteReference Ground(-)

GreenLEFT Rear (+) Input

Green/BlackLEFT Rear (-) Input

PurpleRIGHT Rear (+) Input

Purple/BlackRIGHT Rear (-) Input

OUTPUT HARNESS

WhiteLEFT Front (+) Output GreenLEFT Rear (+) Output

White/BlackLEFT Front (-) Output Green/BlackLEFT Rear (-) Output

GrayRIGHT Front + Output PurpleRIGHT Rear (+) Output

Gray/BlackRIGHT Front (-) Output Purple/BlackRIGHT Rear (-) Output

Note:Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXADCT-4. The same goes for the negative audio

wires. Failure to do this will result in poor bass response and low quality audio.

Adjusting the AXADCT-4 for maximum performance:After completing all of the necessary

connections, turn the AXADCT-4 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and adjust the main volume

control on the stereo to approximately 3/4 maximum volume. Select one of the adjustment

pots on the AXADCT-4 and turn it slowly clockwise until you notice audio distortion and then

stop. Turn the remaining pots to the same position as the previously adjusted pot. The audio

set-up of the AXADCT-4 is now complete and ready to be enjoyed.

Wire Color & Function:The audio and power input wire colors are an EIA standard for car

stereo applications as follows.

INPUT HARNESS POWER HARNESS

WhiteLEFT Front (+) Input YellowBATTERY +12V Input

White/BlackLEFT Front (-) Input BlackPOWER (-) GROUND Input

GrayRIGHT Front + Input BlueREMOTE +12V Output

Gray/BlackRIGHT Front (-) Input Black/WhiteReference Ground(-)

GreenLEFT Rear (+) Input

Green/BlackLEFT Rear (-) Input

PurpleRIGHT Rear (+) Input

Purple/BlackRIGHT Rear (-) Input

OUTPUT HARNESS

WhiteLEFT Front (+) Output GreenLEFT Rear (+) Output

White/BlackLEFT Front (-) Output Green/BlackLEFT Rear (-) Output

GrayRIGHT Front + Output PurpleRIGHT Rear (+) Output

Gray/BlackRIGHT Front (-) Output Purple/BlackRIGHT Rear (-) Output

Note:Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXADCT-4. The same goes for the negative audio

wires. Failure to do this will result in poor bass response and low quality audio.

Adjusting the AXADCT-4 for maximum performance:After completing all of the necessary

connections, turn the AXADCT-4 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and adjust the main volume

control on the stereo to approximately 3/4 maximum volume. Select one of the adjustment

pots on the AXADCT-4 and turn it slowly clockwise until you notice audio distortion and then

stop. Turn the remaining pots to the same position as the previously adjusted pot. The audio

set-up of the AXADCT-4 is now complete and ready to be enjoyed.

Wire Color & Function:The audio and power input wire colors are an EIA standard for car

stereo applications as follows.

INPUT HARNESS POWER HARNESS

WhiteLEFT Front (+) Input YellowBATTERY +12V Input

White/BlackLEFT Front (-) Input BlackPOWER (-) GROUND Input

GrayRIGHT Front + Input BlueREMOTE +12V Output

Gray/BlackRIGHT Front (-) Input Black/WhiteReference Ground(-)

GreenLEFT Rear (+) Input

Green/BlackLEFT Rear (-) Input

PurpleRIGHT Rear (+) Input

Purple/BlackRIGHT Rear (-) Input

OUTPUT HARNESS

WhiteLEFT Front (+) Output GreenLEFT Rear (+) Output

White/BlackLEFT Front (-) Output Green/BlackLEFT Rear (-) Output

GrayRIGHT Front + Output PurpleRIGHT Rear (+) Output

Gray/BlackRIGHT Front (-) Output Purple/BlackRIGHT Rear (-) Output

Note:Be sure that all audio input connections are polarized or in phase with each other.

That is, the positive output wires from the audio source need to be connected to the

corresponding positive input wires of the AXADCT-4. The same goes for the negative audio

wires. Failure to do this will result in poor bass response and low quality audio.

Adjusting the AXADCT-4 for maximum performance:After completing all of the necessary

connections, turn the AXADCT-4 adjustment pots all of the way down by rotating them

completely counter-clockwise. Now, turn the stereo system on and adjust the main volume

control on the stereo to approximately 3/4 maximum volume. Select one of the adjustment

pots on the AXADCT-4 and turn it slowly clockwise until you notice audio distortion and then

stop. Turn the remaining pots to the same position as the previously adjusted pot. The audio

set-up of the AXADCT-4 is now complete and ready to be enjoyed.
