AXPIO-JL1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 3/20/24 INSTAXPIO-JL1

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Panel removal tool • Phillips screwdriver

• Torx screwdrivers

TABLE OF CONTENTS

Dash Disassembly ........................................................2

Kit Assembly

- Radio Provision ..........................................................2

- Pioneer Modular DDIN Radio Provision ...............3

Axxess Interface Installation ...............................4-16

Jeep Wrangler

JL

2018.5-2023 (Excluding 4XE Models)

Note:

This kit will function in both Single-Zone and Dual-Zone vehicles:

• All HVAC functions will be retained.

• Single-Zone vehicles will only get status feedback of the HVAC functions,

while Dual-Zone vehicles can also be controlled through the radio screen.

• Compass is only retained on vehicles equipped with the UConnect 3

(5" touchscreen).

• The External Speaker is only required in vehicles with safety group features.

Attention! Designed specifically for Pioneer’s DMH-W4600NEX/WC4660NEX.

Pioneer 9" DMH-WC6600NEX will require the Metra Floating Mount Kit

109-UN02. (sold separately)

KIT COMPONENTS

• A) Radio bezel • B) Shallow mount brackets (2) • C) Modular radio brackets (2) • D) Panel clips (4)

ABCD

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Included with Kit

Antenna Adapter: Included with Kit

GPS Antenna Adapter: Included with Kit

Visit AxxessInterfaces.com for up-to-date

vehicle specific applications.
