AXDSPX-A2B1

INSTALLATION INSTRUCTIONS

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections ........................................................ 2-3

Installation .............................................................4

LED Feedback .........................................................6

A2B Data Interface with Amplifier

Bypass

Harness & DSP

• Designed for Sony A2B amplifiers

• A2B data interface with AXDSP-X (digital signal processor) built-in

• Includes an amplifier bypass harness

• Retains factory chimes including parking sensor chimes

• Retains SYNC voice prompts

• All chimes/voice prompts go through the aftermarket amplifier

and/or cluster

• Adjustable chime level

• Micro-B USB updatable

• AXDSPX-A2B1 interface

• AXDSPX-A2B1 harness

• AXDSPX-A2B1 interface harness (male connectors: 12-pin, 16-pin)

• Amplifier bypass harness (female connectors: 16-pin, 16-pin)

• Radio T-harness

• AXBK-1

Google Play Store

Apple App Store

iOS 12.1 or higher

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator lights,

are plugged in before reconnecting the battery or

cycling the ignition to test this product.

NOTE: Refer also to the instructions included with

the aftermarket radio.

Metraonline.com

For Dash Disassembly Instructions, refer to Metraonline.com. Enter the year, make, and model of the vehicle in the Vehicle Fit Guide for Radio Install kits.

Visit Axxessinterfaces.com for current application list.

Visit MetraOnline.com and Axxessinterfaces.com for harness and interface options.
