AXVI-1784
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
AXVI-1784
AXVI-1784 AXVI-1784
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
AXVI-1784
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
AXVI-1784
DODGE
Sprinter 2007
Sprinter
(sound 5 radio) 2008-2009
MERCEDES
Sprinter
(sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
DODGE
Sprinter 2007
Sprinter
(sound 5 radio) 2008-2009
MERCEDES
Sprinter
(sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
AXVI-1784
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
AXVI-1784
DODGE
Sprinter 2007
Sprinter
(sound 5 radio) 2008-2009
MERCEDES
Sprinter
(sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
DODGE
Sprinter 2007
Sprinter
(sound 5 radio) 2008-2009
MERCEDES
Sprinter
(sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
AXVI-1784
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
AXVI-1784
AXVI-1784 AXVI-1784
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface has been initialized, plug in the AXSWC into the 12 pin harness
of the AXVI-1784 and refer to the AXSWC instructions.
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface has been initialized, plug in the AXSWC into the 12 pin harness
of the AXVI-1784 and refer to the AXSWC instructions.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface has been initialized, plug in the AXSWC into the 12 pin harness
of the AXVI-1784 and refer to the AXSWC instructions.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface has been initialized, plug in the AXSWC into the 12 pin harness
of the AXVI-1784 and refer to the AXSWC instructions.
Produktspecifikationer
| Varumärke: | Axxess |
| Kategori: | ej kategoriserat |
| Modell: | AXVI-1784 |
Behöver du hjälp?
Om du behöver hjälp med Axxess AXVI-1784 ställ en fråga nedan och andra användare kommer att svara dig
ej kategoriserat Axxess Manualer
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
ej kategoriserat Manualer
- Cateye
- ZOTAC
- Thermador
- Cherry
- Ultimate Speed
- Synco
- Kuppersbusch
- Hansgrohe
- Datapath
- xTool
- Yadea
- Blustream
- Worx
- Izzy
- BMW
Nyaste ej kategoriserat Manualer
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
8 Oktober 2025
