Sida 1/2
MODULO TR
cod.15068
334.902.493 C
A B
www.beghelli.com
BEGHELLI S.p.A. - Via Mozzeghine 13/15 - località Monteveglio 40053 Valsamoggia (BO) - Tel. +39 051 9660411 - Fax +39 051 9660444 - N° Verde 800 626626
IP66IK07
2
3
0
V
ac
-
5
0
/
6
0
Hz
0
<
ta<
4
0
°
C
SETTAGGI - SETTINGS
C
COLLEGAMENTO - CONNECTION
Per approfondimenti e aggiornamenti inquadra il codice QR sul prodotto
For further information and updates, scan the QR code on the product
battery connector
SE
AL CONNETTORE 2 POLI (LED)
TO THE 2 POLE CONNECTOR (LED)
L N T Pu
D+ D- L+ L-
230Vac
2730 optional
Utilizzare il pressacavo (M20) della lampada
Use the lamp cable gland (M20)
Per il cablaggio della
morsettiera fare riferi-
mento al manuale della
lampada
For wiring the terminal
block, refer to the lamp
manual
Ord. Code
230V
50Hz
COS ϕ
P out LED
15068 36mA 0,47 5 - 1,7W LiFe 6,4V 1,5Ah 1-3h
D
MONTAGGIO STAFFA - BRACKET ASSEMBLY
Assemblare il modulo emergenza sulla staffa della lampada
Assemble the emergency module on the lamp bracket
Autonomia:
- 1h circuito integro
- 3h circuito tagliato
Autonomy:
- 1h circuit intact
- 3h circuit wire
Connettere la batteria DOPO il taglio del circuito per la sele-
zione dell'autonomia
Connect the battery AFTER cutting the circuit for auto-
nomy selection
*60
*60
180
