CCR1072-1G-8S+

CCR1072-1G-8S+CCR1072-1G-8S+

CCR1072-1G-8S+

The CCR1072 is a high-performance multicore router with eight SFP+ cages. Ports are directly connected to a Tilera 72 core CPU and assisted by 16 GB

of built-in ECC RAM.

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents.

Ultimate disposal of this product should be handled according to all national laws and regulations.

The Installation of the equipment must comply with local and national electrical codes.

This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

Read the installation instructions before connecting the system to the power source.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your

own risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.

First use

The Ethernet port 1 (BOOT) has a default IP address for connecting: 192.168.88.1 username is admin and there is no password (or, for some models,

. Please connect with your web browser to this IP address and choose Webfig to configure it. The device check user and wireless passwords on the sticker)

doesn't have any other configuration applied by default, please connect to it, and set up WAN IP addresses, user password, firewall, etc. Please see the co

section.nfiguration

Mounting

The device is designed to use indoors and it can be mounted in a rackmount enclosure using provided rack mounts, or it can be placed on the desktop.

Use a Phillips screwdriver to attach rackmount ears on both sides of the device if designated use is for rackmount enclosure:

Attach rack ears to both sides of the device and tighten four screws to secure them in place, as shown on the picture to the right;

Place the device in rackmount enclosure and align with the holes so that the device fits conveniently;

Tighten screws to secure it in place.

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	Router
Modell:	CCR1072-1G-8S+
Vikt:	3800 g
Bredd:	443 mm
Djup:	315 mm
Höjd:	44 mm
Processorfrekvens:	1000 MHz
Internminne:	16384 MB
Återställningsknapp:	Ja
Rackmontering:	Ja
Ethernet WAN:	Ja
Flashminne:	128 MB
Genomströmning:	80 Gbit/s
Rackkapacitet:	1U
Spänningsövervakning:	Ja
Typ av minneskort:	MicroSD (TransFlash)
Produktens färg:	Vit
Antal USB-portar:	2
Vikt inkl. förpackning:	5125 g
Inbyggd processor:	Ja
Installerat operativsystem:	RouterOS
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Strömförbrukning (vanlig):	125 W
Temperatur vid drift:	-20 - 60 ° C
AC-inspänning:	100 - 240 V
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	AC
Processorkärnor:	72
Harmonized System (HS)-kod:	85176990
Faktisk dataöverföringshastighet:	10000 Mbit/s
Lagringsmedia:	Flash
Antal installerade SFP+-moduler:	8
Temperaturbevakning:	Ja
