RouterBOARD 900 series
Quick Setup Guide and Warranty Information
RB900 is a RouterBOARD device family with a built-in 802.11 wireless device and one Ethernet port. Several mod-
els are available with 5GHz or 2GHz 802.11n or 5GHz 802.11ac wireless, with SFP slot, and miniPCIe slot.
First use
• Connect antenna cables to the built in Wi-Fi connectors
• Device accepts 8-30V with a passive PoE powered Ethernet cable or with a power connector to the Power
Jack
Powering
The board accepts power with the following modes:
•
Passive 8-30V PoE to ethernet port. Higher voltage needed to compensate for power loss on long cables;
at least 18V suggested.
•
Direct input to the power jack 8-30V (select models only)
Booting process
RouterOS is the operating system of all RouterBOARD routers. Please see documentation here: http://mt.lv/help
This device doesn't come fitted with a Serial Port connector, so initial connection has to be done via the Ethernet
cable, using the MikroTik Winbox utility. Winbox should be used to connect to the default IP address of
192.168.88.1 adminwith the username and . no password
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of
the device when starting it until the LED light turns off, and Groove will start to look for Netinstall servers.
In case IP connection is not available, the Winbox utility can also be used to connect to the MAC address of the
device. More information in the documentation.
Extension Slots and Ports
•
One Ethernet port (With Auto MDI/X so you can use either straight or cross-over cables for connecting to
other network devices). The Ethernet port accepts 8-30V DC powering from a passive PoE injector.
•
Built-in 802.11b/g/n WiFi card (AR9342) with one or two MMCX connectors
•
Only RB912UAG-2HPnD/RB912-5HPnD/RB922UAGS-5HPacD/RB922UAGS-5HPacT: !
miniPCI-e slot for either a 802.11 Wireless card, or a 3G modem (when a 3G modem is used in miniPCIe
slot, USB port will become inactive. In RouterOS you can select which of the 3G modems you want to use,
USB or miniPCIe). SIM slot is available for miniPCIe 3G cards.
•
Only RB922UAGS-5HPacD/ RB922UAGS-5HPacT: !
One SFP port for 1.25GBit modules, DDMI support
Buttons and Jumpers
•
RouterOS reset jumper hole – resets RouterOS software to defaults. Must short circuit the metallic sides of
the hole (with a screwdriver, for example) and boot the device. Hold screwdriver in place until RouterOS
configuration is cleared.
•
Reset button – Holding this button during boot time will make the RouterBOARD look for Netinstall servers.
Release the button after the LED light goes out.
Operating System Support
Currently tested operating system is MikroTik RouterOS (starting from version v6.30).
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 26 Oct 2016
