RouterBOARD+750UP+
Quick&Setup&Guide&and&Warranty&Information&
The$RB750UP$is$a$router$with$five$Ethernet$ports.$It$has$one$USB$2.0$port,$and$supports$PoE$power$output$ $to$
ports$2?5$(500mA$maximum$per$port).$
First&use&
• Connect$your$WAN$cable$to$port$1,$$
and$LAN$computers$to$ports$2?5$
• Set$LAN$computer$IP$configuration$to$automatic$(DHCP)$
• RB750UP$Default$IP$address$from$LAN$is$192.168.88.1$
Powering&
The$board$accepts$powering$from$the$power$jack$or$from$the$
first$Ethernet$port$(Passive$PoE):$
• direct?input$power$jack$(5.5mm$outside$and$2mm$inside,$female,$pin$positive$plug)$accepts$8? $28V$DC
• first$Ethernet$port$accepts$passive$Power$over$Ethernet$accepts$8? $28V$DC
Normally$the$power$consumption$of$this$device$is$2.4W,$under$maximum$load$?$ $3.6W
Power&output&
This$RouterBOARD$device$can$supply$PoE$powering$to$external$devices$from$its$Ethernet$ports.$This$is$convenient$as$
you$don't$need$any$additional$PoE$injectors$to$power$other$devices.$This$feature$is$indicated$by$the$letter$“P”$in$the$
device$model$name.$The$output$Voltage$will$be$the$same$as$input$Voltage,$and$this$feature$will$have$to$be$enabled$
on$the$specific$ports$in$RouterOS$software.$By$default$it$is$disabled.$Maximum$power$output$of$each$ethernet$port$in$
this$mode$is$500mA.$Once$Power$Output$is$enabled$in$RouterOS,$the$Ethernet$LED$light$turns$from$Green,$to$Red.$
Read$LED$means$the$port$is$currently$providing$PoE$power.$$
Booting&process&
This$device$doesn't$come$fitted$with$a$Serial$Port$connector,$so$initial$connection$has$to$be$done$via$the$Ethernet$
cable,$using$the$MikroTik$Winbox$utility.$Winbox$should$be$used$to$connect$to$the$default$IP$address$of$192.168.88.1+
with$the$username$admin$ $and$no$password.
In$case$IP$connection$is$not$available,$Winbox$can$also$be$used$to$connect$to$the$MAC$address$of$the$device.$More$
information$here:$http://wiki.mikrotik.com/wiki/First_time_startup$
In$case$you$wish$to$boot$the$device$from$network,$for$example$to$use$MikroTik$Netinstall,$hold$the$RESET$button$of$
the$device$when$starting$it$until$the$LED$light$turns$off,$and$RB750$will$start$to$look$for$Netinstall$servers.$
Extension&Slots&and&Ports&
• Five$individual$Ethernet$ports,$supporting$automatic$cross/straight$cable$correction$(Auto$MDI/X),$so$you$can$
use$either$straight$or$cross over$cables$for$connecting$to$other$network$devices.$The$Ethernet$port$accepts$?
8?28$V$DC$powering$from$a$passive$PoE$injector,$12V$or$more$is$recommended$to$compensate$for$loss$in$
cables.$
www.routerboard.com 2 2- - Jul 2012
Buttons&and&Jumpers&
• ROS$reset$jumper$hole$(on$the$bottom$of$case,$behind$one$of$the$rubber$feet)$–$resets$RouterOS$software$to$
defaults.$Must$short$circuit$the$metallic$sides$of$the$hole$(with$a$screwdriver,$for$example)$and$boot$the$
device.$Hold$screwdriver$in$place$until$RouterOS$configuration$is$cleared.$$$
• RouterBOOT$reset$button$(RESET,$front$panel)$has$two$functions:$
o Hold$this$button$during$boot$time$until$LED$light$starts$flashing,$release$the$button$to$reset+
RouterOS+configuration+(same$result$as$with$reset$hole)$
o Hold$this$button$during$boot$time$longer,$until$LED$turns$off,$and$then$release$it$to$make$RB750$look+
for+Netinstall+servers.$
Operating&System&Support&
Currently$tested$operating$system$is$MikroTik$RouterOS$(starting$from$v4.17).$
Copyright&and&Trademarks.&
Copyright$MikroTikls$SIA.$This$manual$contains$information$protected$by$copyright$law.$No$part$of$it$may$be$
reproduced$or$transmitted$in$any$form$without$prior$written$permission$from$the$copyright$holder.$RouterBOARD,$
RouterOS,$RouterBOOT$and$MikroTik$are$trademarks$of$MikroTikls$SIA.$All$trademarks$and$registered$trademarks$
appearing$in$this$manual$are$the$property$of$their$respective$holders.$
Hardware.$MikroTik$warrants$all$RouterBOARD$series$equipment$for$the$term$of$fifteen$(15)$months$from$the$
shipping$date$to$be$free$of$defects$in$materials$and$workmanship$under$normal$use$and$service,$except$in$case$of$
damage$caused$by$mechanical,$electrical$or$other$accidental$or$intended$damages$caused$by$improper$use$or$due$to$
wind,$rain,$fire$or$other$acts$of$nature.$
To$return$failed$units$to$MikroTik,$you$must$perform$the$following$RMA$(Return$Merchandise$Authorization)$
procedure.$Follow$the$instructions$below$to$save$time,$efforts,$avoid$costs,$and$improve$the$speed$of$the$RMA$
process.$
• If$you$have$purchased$your$product$from$a$MikroTik$Reseller,$please$contact$the$Reseller$Company$regarding$
all$warranty$and$repair$issues,$the$following$instructions$apply$ONLY$if$you$purchased$your$equipment$
directly$from$MikroTik$in$Latvia.$
• We$do$not$offer$repairs$for$products$that$are$not$covered$by$warranty.$Exceptions$can$be$made$for$RB1000,$
RB1100$and$RB1200.$
• Out? ?of warranty$devices$and$devices$not$covered$by$warranty$sent$to$MikroTikls$will$be$returned$to$the$
sender$at$sender's$cost.$
RMA$Instructions$are$located$on$our$webpage$here:$http://rma.mikrotik.com$
Manual.$This$manual$is$provided$“as$is”$without$a$warranty$of$any$kind,$expressed$or$implied,$including,$but$not$
limited$to,$the$implied$warranty$of$merchantability$and$fitness$for$a$particular$purpose.$The$manufacturer$has$made$
every$effort$to$ensure$the$accuracy$of$the$contents$of$this$manual;$however,$it$is$possible$that$it$may$contain$
technical$inaccuracies,$typographical$or$other$errors.$No$liability$is$assumed$for$any$inaccuracy$found$in$this$
publication,$nor$for$direct$or$indirect,$incidental,$consequential$or$other$damages$that$may$result$from$such$an$
inaccuracy,$including,$but$not$limited$to,$loss$of$data$or$profits.$Please$report$any$inaccuracies$found$to$
support@mikrotik.com$
