Sida 1/3
Quick Guide
Kurzanleitung
Guide rapide
Guida rapida
Guía de inicio rápido
Pikaohje
Γρήγορος οδηγός
Kısa Kılavuz
Краткая инструкция
Guia rápido
Beknopte handleiding
Krótka instrukcja obsługi
Snabbguide
Kort vejledning
快速指南
クイックガイド
퀵 가이드
    · ·  .  · 
     - () /  · -
@. · ..
.  / · /
Miniature Clip Microphone
Specifications MCM 114 (
KK 14 with MCM 100)
Acoustic operating principle
Directional pattern
Frequency range
Sensitivity at 1 kHz into 1 kΩ
Rated output impedance
Rated load impedance
Signal-to-noise ratio, CCIR
1)
(rel. 94 dB SPL)
Signal-to-noise ratio, A-weighted
1)
(rel. 94 dB SPL)
Equivalent noise level, CCIR
1)
Equivalent noise level, A-weighted
1)
Maximum SPL
2)
for THD < 0.5 %
with MCM 100, U
supply
= 10 V, R
feed
= 20 kΩ
with U
supply
= 5 V, R
feed
= 8.25 kΩ
Dynamic range of the amplifier, A-weighted
2)
for THD < 0.5 %
Power supply
Current consumption
Required connector
Weight
Dimensions (Ø x L)
Operating temperature range
Storage temperature range
Operating humidity range
Storage humidity range
Pressure gradient transducer
Cardioid
20 Hz - 20 kHz
3.6 mV/Pa 49 dBv ± 2 dB
KK 14: 10 Ω | MCM 100: 50 Ω
1000 Ω
63 dB
71 dB
31 dB
23 dB-A
153 dB SPL
147 dB SPL
130 dB
KK 14: ≤ 10 V, with R
feed
= 20 kΩ | MCM 100: 48 V ± 4 V (P48, IEC 61938)
KK 14: 0.22 mA | MCM 100: 3.5 mA
XLR-3F
KK 14: 2.3 g | MCM 100: 96 g
KK 14: Ø 12 mm x 11 mm | MCM 100: Ø 22 mm x 77 mm
0 °C - +40 °C (32 °F - 104 °F)
−20 °C - +70 °C (−4 °F - 158 °F)
0 % - 90 %
0 % - 95 %
1)
according to IEC 60268-1; CCIR-weighting according to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
2)
THD of microphone amplifier at an input voltage equivalent to the capsule output at the specified SPL
KK 14
MCM capsule head KK 14 cardioid
MCM 114 set high strings
MCM 114 set cello
MCM 114 set bass
MCM 114 set woodwinds
MCM 114 stereo set piano
MCM 114 set guitar
MCM 114 set brass/sax/uni
MCM 114 set drums
SH 150
MCM gooseneck 150 mm
MCM 100
MCM output stage XLR
WS 110
MCM windscreen soft
AC 31
MCM cable mini jack 1.8 m
MC 1
MCM clip high strings
MC 2
MCM strings clip cello
MC 3
MCM strings clip double bass
MC 4
MCM rib clip double bass
MC 5
MCM universal strap clip
MC 6
MCM universal clamp clip
MC 7
MCM clip drum rims
MC 8
MCM magnetic piano clip
MC 9
MCM clip guitar
KC 1
MCM cable brace
softcase
MC 1Clips MC 2 MC 3 MC 4 MC 5 MC 6 MC 7 MC 8 MC 9
Suitable for
Clip aperture
(with reducer)
Diameter of
strings
Weight
violin, viola,
mandolin,
32 - 50 mm
-
16 g
cello
-
0.6 - 2.3 mm
12 g
double bass
-
1 - 2.6 mm
20 g
double bass
202 - 246 mm
(169 - 213 mm)
-
38 g
oboe, clarinet,
recorder,
basson, flute,
harp
10 - 80 mm
-
20 g
trumpet,
trombone,
saxophone,
french horn,
percussion,
stands
0 - 20 mm
-
20 g
tom, snare,
stand tom
-
-
10 g
piano,
grand piano
-
-
20 g
acoustic guitar,
ukulele, dobro,
acoustic bass,
cello
85 - 132 mm
(52 - 99 mm)
-
25 g
Specifications SH 150
Overall length
Weight
194 mm
20 g
SH 150
MCM gooseneck 150 mm
KC 1
MCM cable brace
MCM 100
MCM output stage XLR
AC 31
MCM cable mini jack 1.8 m
(works with AC 31 only)
AC 32
MCM cable LEMO 3 pin 1.8 m
optional accessories:
bodypack transmitter
AC 33
MCM cable MicroDot 1.8 m
AC 34
MCM cable mini XLR 4 pin 1.8 m
MC 1
MCM clip high strings
MC 2
MCM strings clip cello
MC 3
MCM strings clip double bass
MC 4
MCM rib clip double bass
MC 5
MCM universal strap clip
MC 6
MCM universal clamp clip
MC 7
MCM clip drum rims
MC 8
MCM magnetic piano clip
MC 9
MCM clip guitar
KK 14
MCM capsule head KK 14 cardioid
WS 110
MCM windscreen soft
