59-3064-1 2212-27
EN
INS-HX-80N
INS-HX-80N
VISUAL VERIFICATION PIR CAMERA
INSTALLATION INSTRUCTIONS
1
2
3
4
5
- Manufacturer's statement
- Parts identification
- Accessories
- Specifications
- Dimensions
- Detection area
- LED indication
- Compliance
- How to reset to the factory default
Before installation
Others
<< Contents >>
1-1. Remove the mounting plate
1-2. Install the mounting plate using 2 screws
1-3. Connect cables to the device
1-4. Secure the main body
Page
2
3
5
6
13
14
Step
Enabled
Disabled
Installation
IP address settings
DHCP
Camera angle and PIR area settings
Checking
series
1
InSIght Camera manual
CHeKT support
Refer to the InSight Camera manual for details on
IP address settings.
InSIght Camera manual
https://navi.optex.net/manual/50427/en/?type=cameramanual
If you do not have a CHeKT account, request a dealer account
by visiting the CHeCK dealer site, before Step 3.
CHeKT dealer
www.chekt.com/registration
Refer to the CHeCK support site for more details.
CHeKT support
https://support.chekt.com
5-1. Walk test
5-2. System check
4-1. Horizontal adjustment
4-2. Vertical adjustment
4-3. PIR/VCA settings
4-4. PIR area masking
4-5. Switch settings
4-6. Put on the back cover
Device registration to CHeKT portal
- Manufacturer's statement
Failure to follow the instructions provided
with this indication and improper handling
may cause death or serious injury.
Failure to follow the instructions provided
with this indication and improper handling
may cause injury and/or property damage.
Check mark indicates recommendation.
Nix sign indicates prohibition.
Special attention is required to the section
of this symbol.
Symbol Meaning
Symbol Meaning
Warning
Caution
NOTE
Warning
Caution
Before installation
Destroy
Disassemble
modify
Intentional watering
Mounting height
Tilt
2.5 m (8’ 2” ) to 3.0 m (10’ )
2
- Parts identification
4 x 20 mm
Mounting screws
T20 Torx wrench
Waterproof cap
for LAN connection
PIR detector
Bracket angle adjusting screw
PIR cover
Camera unit
Camera angle adjusting screw
Back cover
Mounting plate
- Accessories
Mounting on
an unstable
wall
