Sida 1/2
Free-standing 360° or 180° view
and wall mounted TW beam towers
The TW, STW and STWM towers are suited for all OPTEX
®
AX and Smart Line
™
(SL) wired, IP and wireless infrared beams models
Concealing active infrared beams in towers increases the
security and exibility of perimeter protection systems.
OPTEX Dual and Quad IR beams can be mounted directly on walls
or poles, however by installing them in towers, it makes them less
obvious. The number and height of the tted beams becomes unknown
to the potential intruders, enhancing this way the security level.
Additionally, the options to mount lighting or a xed camera in a special
housing on top of the towers allows a complete security system to blend
nicely into its environment.
n
Free standing models TW provide 360° unobstructed view for
the beams, enabling back to back installation to cover a whole
perimeter
n
Free-standing STW models provides 180° view enabling side
detection for sites where wall mount is not a possible or
practical option
n
Wall mounted STWM models features 180° view and ush mount
n
0.5m/1m/1.5m/2m/3m heights available
n
Durable construction with extruded aluminium frame and
acrylic materials
n
Beams can be mounted at any height and direction in the tower
n
Additional housing and xings for lighting or xed cameras
available as options
n
Anti-tamper and full xing kit for the tower itself supplied
n
Suitable for all wired, IP and wireless OPTEX AX and Smart Line (SL)
models (consult us for the list of accessories needed)
Tower part numbers
Fixing kit for the OPTEX beam set
Two models of beam support plates are available, and the selection will depend on the OPTEX beam models
to be installed. Each kit mentioned below includes two plates, one for the transmitter and one the receiver.
For wireless beams, an additional battery holder would be needed, please contact us for more information or consult our
beam tower guide on our website.
TWSAX
TWSAX is a kit of two plates, designed
to mount the OPTEX AX-TN/TF beam
models. Only one TWSAX kit is necessary
per beam set.
TWSSL
TWSSL is a kit of two plates, designed to
mount the OPTEX Smart Line (SL) and the
AX-TFR beam models. Only one TWSSL kit
is necessary per beam set.
1000 / 1500 / 2000 mm
244 mm
182 mm
3000 mm
239 mm
219 mm
Beam tower
cover
TW 360°
free-standing towers
TW, STW & STWM
Common accessories
TWAA
Anti-climb
tamper
TWH 24V
12V or 24V,
250mA, non
polarity heater
TWE
Tower head
extension for
lighting (lighting
bulb not
included)
TW FAN
12V/24V
12V, 100mA fan
(TW Fan 12V)
24V, 150mA fan
(TW Fan 24V)
OPTEX (EUROPE) LIMITED
EMEA Headquarters
T: +44 (0)1628 631 000
Dubai branch
T: +971 (0)4 501 53 94
E: marketing@optex-europe.com
www.optex-europe.com
OPTEX Security SAS
(France, French speaking North
and West African countries)
OPTEX Security SAS
T: +33 (0)4 37 55 50 50
E: contact@optex-security.com
www.optex-security.com
OPTEX Security Sp. z o.o.
(Eastern Europe,
CIS countries, Turkey)
Optex Security Sp. z o.o.
T: +48 (22) 598 06 60
E: optex@optex.com.pl
www.optex.com.pl
OPTEX Technologies BV
(Benelux)
OPTEX Technologies B.V.
T: +31 70 4194100
E: info@optex.eu
www.optex.eu
STW 180°
free-standing towers
STWM 180°
wall-mounting towers
Ground mounting, 360°
TW50 50cm 360º Beam Tower Floor
TW100 1m 360º Beam Tower Floor
TW150 1,5m 360º Beam Tower Floor
TW200 2m 360º Beam Tower Floor (standard height)
TW300 3m 360º Beam Tower Floor (lateral supports incl.)
Ground mounting, 180°
STW050 50cm 180º Beam Tower Floor
STW100 1m 180º Beam Tower Floor
STW150 1,5m 180º Beam Tower Floor
STW200 2m 180º Beam Tower Floor
STW300 3m 180º Beam Tower Floor
Wall mounting, 180° (Flush Mount)
STW050M 50cm 180º Wall Mount Beam Tower
STW100M 1m 180º Wall Mount Beam Tower
STW150M 1,5m 180º Wall Mount Beam Tower
STW200M 2m 180º Wall Mount Beam Tower
STW300M 3m 180º Wall Mount Beam Tower
TW TW 300
STW
STW 300
STWM
TWT
Thermostat for
heater
TWT-50
Thermostat for
fan (for high
temperature)
TWEB
Concrete oor
bracket for the
double sided
free standing
beam towers
STWEB
Concrete oor
bracket for the
STW single
sided free
standing beam
towers
