www.avsl.com 151.594UK User Manual
Pixel-Bar
Pixelated LED Wall Strobe Bar
Item ref: 151.594UK
User Manual
The QTX Pixel-Bar LED wall strobe bar is fitted with 224 RGB SMD's to provide a wide range of bright and
colourful patterns and effects. Various automatic shows and settings can be run directly from the unit or
using sound to light. Alternatively, the bar can be operated remotely by DMX in various channel modes
and connected to more units if a larger effect is needed.
In the box:
Your Pixel-Bar should arrive with you in a single carton in good condition. The carton should contain
1x main unit, 2x fixing stand/brackets with thumbscrews, 1x clear diffuser, 1x UK IEC mains lead and 1x
manual.
Warning:
To prevent risk of fire or electric shock, do not expose the unit to rain or damp environments. In the event
of a spillage, disconnect the mains and allow the unit to dry out naturally. Qualified personnel should then
check the unit before continuing use.
Placement:
• Use the included mounting brackets to fix to a stand or lighting truss.
• Use secondary safety fixings if mounting overhead.
• Keep away from damp or dusty environments.
• Ensure adequate airflow around the fixture housings.
• Ensure adequate access to controls and connections.
• Do not aim LED output directly into line of sight, as this can result in eye injury.
Please read through this manual thoroughly before use, any damage
caused by misuse of product will not be covered by warranty.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
er or professional when unit malfunction.
www.avsl.com 151.594UK User Manual
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required.
• Do not use strong solvents for cleaning the unit.
Side panel controls:
Manual control menu:
Press the “MENU” button to enter the settings menu.
Press “UP” and “DOWN” buttons to navigate through various setting functions.
Press “ENTER” button to confirm the desired setting.
Mode
Programming
Description
Auto mode
Auto
SP1 - SP10
Auto mode
Auto mode speed adjust – slow to fast
DMX mode
Addr
3CH
A001-A510
5CH
A001-A508
8CH
A001-A505
24CH
A001-A489
48CH
A001-A465
53CH
A001-A460
Show mode
Shou
Sh1-Sh54
Programmed show modes 1-54
Sp1-Sp10
Show mode speed adjust – slow to fast
St0-St9
Show mode strobe adjust – slow to fast
Sound mode
Soud
Sou1-Sou3
Sound activated modes
Sen1-Sen9
Sound activated mode sensitivity adjustment – low to high
Edit colour
Colo
r000-255
Red dimming 0-100%
G000-G255
Green dimming 0-100%
b000-b255
Blue dimming 0-100%
Static Colours
Stat
CL00-CL26
RGB static colour select
Slave
Slav
Slav
Slave automatically identifies the host
Setting adjust
Set
dis
Backlight board time adjust - 10s, 20s, 30s, 60s, on (default is
10 seconds)
dir
Setting direction - or → (left or right)
Information
Info
Ver
Displays current software version
