X70 Series Quick Guide

【

English

】

53R-X70003-2001

VESA mounting it to the wall

Placing on the desk

Front/Rear/Side View



Run the screen calibration

program and correct 4 point

locations on screen with the

panel.

Click

Start / All Programs

/ eGalax Touch

 /CongureUtility

Select

[Tools] tab and click

[4 Points Calibration]

How to use the Touch Panel (Optional)



When the 4 points calibration completed,

press to continue.[OK]

4 Point Calibration (Optional)

X70 brings digital life for an easy touch experience.Experience

the ease of managing your digital life with a few touches.

 Thetouchofyourngerreplacesthemouseandisallyouneed

to interact with the X70.



Touch and hold the center of the target.

Repeat on four corners and the screen will

adjust automatically.

Cleaning the screen

Follow these guidelines for cleaning the outside and handling the screen

of the computer:

Turn off the system and disconnect all cables.

Use a damp, or cleaning cloth, soft, lint-free cloth with gentle water only

and gently wipe the screen surface.

Do not spray liquid directly on the screen.

・Touch = left-click on the mouse

・Touch and hold = right-click on the mouse

Follow the steps (1~3) below to connect the AC adapter to the jack.DC in

Press the to turn on the system.Power Button

Poweringonthesystem

Note : X70 can be mounted to a wall using a VESA

compatible 100 x 100mm wall/arm bracket.

If you are mounting your X70 to the wall, remove the cover

 onthebackofX70rst.

Unscrew three screws of the stand mount and remove the

stand.

The VESA standard lets users mount it on to walls easily.

Please refer to the user guide of the wall/arm mount kit you

bought to install it.

Note: Theproduct’scolorandspecicationwilldependupontheactuallyshippingproduct.

SafetyInformation

Read the following precautions before setting up a Shuttle X70.

Hold OK

62R-X70000-0601 X70

English.Spanish.Korean.

Traditional Chinese.Japanese.

French. German Quick Guide

To place the machine on the desk and to carry it, do the following:

 PlacetheX70onaatsurfacesuchasatable(Picture1),andpullthestand

upwards to an angle of 30°, the support bracket can be opened to 60 degrees at

most(Picture 2). To carry or move your X70, turn back the angle to 0° (Picture 3).

wer

Butto

DCIN

3.2.1.

Max 60

CAUTION 1.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer’s instructions.

CAUTION 2.

Do not walk on the power cord or allow anything to rest on it.

The warranty does not apply to the products that have been disassembled by users.

Touch

COM Port

USB 3.0 Port

Clear CMOS Button

DC in

COM Ports (Optional)

Webcam

Microphone

LCD Display (Optional)

USB 2.0 Ports

Kensington® Lock Port

USB 2.0 Ports

Printer Port (Optional)

Stand / Handle

HDMI Port

Power Button

Microphone Jack

Stereo speakers

Headphone / Line-out Jack

Lan Ports

Thermal Vent

USB 2.0 Ports

SD Card Reader

Power LED

Hard Disk Drive LED

(Single/Multi/Non Touch)

07 08

10 11

1412 15

A.BeginInstallation

1. RemovethecoveronthebackofX70󰘰rst,unscrew

 threescrewsofthestandmountandremovethestand.

Forsafetyreasons,pleaseensurethatthepower

cordisdisconnectedbeforeopeningthecase.

B.ICEandCPUInstallation

2.

Unscrewfourscrewsofthebackcoverandremoveit.

C.MemoryModuleInstallation

1. LocatetheSODIMMslotonthemainboard.

3. Gentlyinsertthemoduleintotheslotina45-degree



 angle.

2. Alignthenotchofthememorymodulewiththeone



 ofthememoryslot.

SODIMM slot

5.

Repeattheabovestepstoinstalladditionalmemory

 modules,ifrequired.

4. Carefullypushdownthememorymoduleuntilit



 snapsintothelockingmechanism.

1. Replacethebackcover,standandrefastenseven



 screws.

E.Complete

2. Replacethecover,complete.

3. RemovethefansandICEmodulefromthechassis

 andputthemaside.



FollowthestepsbelowtocorrectlyinstalltheCPUintothe

 motherboardCPUsocket.

Pleasenotethis1155pinsocketbendseasily.

Alwaysapplyextremecareandlittleforcewhen

installingaCPUandlimitthenumberoftimesyou

removeorexchangeit.Beforeinstallation,make

suretoturno󰘯thecomputerandunplugthepower

cordfromthemainstoavoiddamage.

1. Unscrewthescrewofthebracketandremoveit.

2. MountHDDintothebracketwithfourscrews.

6.ReplacetheVESABaseandrefastenfourscrews.

D.HDDInstallation

45-degree

angle

Back Cover

1. UnscrewthefourscrewsoftheVESABaseandremove

 it󰘰rst.

2. Unscrewthefourscrewsofthethefansandunplugthe



 fanconnectors(Step1),thenunfastenthefourICE

 moduleattachmentscrews(Step2).

Triangle

Pin1

Marking

on the

CPU

Notch on

the CPU/

Alignment

Key of the

CPU Socket

Socket

1155

CPU

Pleasedonotapplyexcessamountofthermalpaste.

9.ScrewtheICEmoduletothemainboard.Notetopress

 downontheoppositediagonalcornerwhiletightening

 eachscrew.

4. Firstunlockandraisethesocketlever.

6. OrientatetheCPUandsocketandpleasealignthe



 CPUnotcheswiththesocketalignmentkeys.Make

 suretheCPUisperfectlyhorizontal,insertitintothe

 socket.

5. LiftthemetalloadplateontheCPUsocket.Tear



 o󰘯theprotectivemembranefromthebottomofICE

 module.Removetheprotectivesocketmylarfromthe

 CPUsocket.

DO NOT touch socket contacts. To protect the

CPU socket, always replace the protective socket

cover when the CPU is not installed.

Remove the

protective

membrane

Metal

load plate

7. Closethemetalloadplate,lowertheCPUsocketlever

 andlockinplace.

Retention

tab

Metal load

plate

Thermal

Paste

application

area

Load lever

8. SpreadthermalpasteevenlyontheCPUsurface.

3. Asshown,installtheHDD&bracketinthechassis

 andpushittowardsthedirectionasindicatedbythered

 arrow.

4. TightentheHDD&bracketwithonescrew.

5. ConnecttheSerialATAandpowercablestotheHDD.

Screw

Stand / Handle

Cover

PleasebeawareoftheCPUorientation,DONOT

forcetheCPUintothesockettoavoidbendingof

pinsonthesocketanddamageofCPU!

10.Fastenthefanswiththefourscrewsandconnectthe

fanconnectors.

SerialATA

PowerCable

SerialATA

Cable

Step 1

Step 2

HDD

FanFan

ICE

module

Stand / Handle
