Sida 1/8

asdf

3950 NW 120th Ave, Coral Springs, FL 33065 TEL 561- -9770 FAX 561- -955 955 9760

CHRY UNI-CAM v2

Chrysler/Dodge/Jeep uConnect (RA4/RA3/RA2)

Dual Camera/Control in Moon Interface

NTV-KIT759

BHM

07/2 /11 6

NTV DOC263

Compable with select 8.4” & 5” uConnect radios

BHM

07/21 6 /1

NTV-DOC202

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

2 | P a g e

Overview

The CHRY UNI-CAM system interfaces up to 2 aermarket cameras v2 to the factory 8.4” or 5”

touch screen in compable 2013+ Chrysler, Dodge and Jeep vehicles. Addionally, the user can

force either camera to display on screen at any me, in any gear*. *OEM rear camera force not

supported.

Kit Contents

Compability (RA4/RA3/RA2: 8.4” or 5” Radios)

2013+

2014+

2015+

CHRYSLER

300 (8.4” only)

DODGE

RAM, VIPER

DURANGO

CHALLENGER, CHARGER

JEEP

GRAND CHEROKEE

Plug & Play T-harness

NTV-HAR 246 or

NTV-HAR264

UNI-CAM Module (KT2) v2

NTV-ASY245

USB Cable (updates)

NTV-CAB009

Oponal RAM-CAM available NTV-KIT426

BHM

07/21 6 /1

NTV-DOC202

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

3 | P a g e

PIN Side

CHRY UNI-CAM v2 pin out

PIN #

Descripon

Color

12v (+) Constant

Yellow

INPUT 1 (CIM & VIM acvaon)

Red

INPUT 2 (Force Rear Camera)

Blue

INPUT 3 (Force Front Camera)

Pink

RCA MALE

RCA Shield

CAN HI (Radio Side)

Brown/White

CAN HI (Car Side)

Blue/White

Ground (-)

Black

OUTPUT 1 (Provides 12v (+) ) ACC

White/Red

OUTPUT 2 reverse (Provides 12v (+) )

Blue/White

OUTPUT 3 (Follows internal relay)

White/Purple

RCA Female (Normally Open)

RCA Female (Normally Closed)

CAN LO (Radio Side)

Brown

CAN LO (Car Side)

Blue

2013+ Dodge/Jeep Radio LCD connector pin out

Pin #

Descripon

Color

CAN HIGH

Dark Blue

CAN LOW

White

DIFF Video (+)

Green/Brown

DIFF Video (-)

Green/Orange

Shield

Ground

Black

Constant 12v

Red

Wire Side

Note: Vehicles equipped with a monochrome screen

are not full color LCD screens and are not

compable with the CHRY UNI-CAM.
