Nitecore UM4 Bruksanvisning

Nitecore Batteriladdare UM4

Läs nedan 📖 manual på svenska för Nitecore UM4 (44 sidor) i kategorin Batteriladdare. Denna guide var användbar för 25 personer och betygsatt med 4.9 stjärnor i genomsnitt av 13 användare

Ladda ner PDF

Sida 1/44

UM4

• Automatic and High-Speed Charging

• Real-time Information Display

• Over-Discharged Li-ion Battery Activation

and IMR Battery Restoration

Intelligent USB

Four-Slot Charger

Contents

English

···········································

2

Español

··········································

6

Deutsch

·········································

10

Francais

·········································

14

 Русский

·········································

18

 日本語

·············································

22

 한국어

·············································

26

Italiano

···········································

30

 Română

·········································

34

 简体中文

··········································

38

IMPORTANT NOTICE CONCERNING WARRANTY

SERVICE

Thank you for purchasing! Before using this charger, please nd your

verication code on the package box, and go to http://charger.nitecore.

com/validation (or scan the QR code beside the verification code to

visit on your mobile phone). Type in your verication code and personal

information as required, and submit the page. After verification,

Nitecore will send you a warranty service email. This email and your

registration email address are essential to your possible warranty

application. Before you complete the warranty service registration, you

cannot enjoy our warranty service for your purchase.

-1-

Features

Accessories

Specications

• Intelligent USB Four-Slot Charger

• QC 2.0 input available

• Capable of charging 4 batteries simultaneously and controlling each slot

independently

• Up to 1,500mA charging speed in a single slot

• Compatible with Li-ion and Ni-MH/Ni-Cd batteries with automatic detection

• Automatic detection of battery power level and automatic selection of the

appropriate voltage and charging mode (LiFePO4 and 3.8V Li-ion batteries

excluded)

• Automatic selection between 3 charging modes (CC, CV and -dV/dt)

• Energy-ecient LCD display for real-time charging information

• Capable of manually selecting the charging cut-o voltage and the charging

current

• Automatic detection of large/small capacity batteries and automatic selection

of appropriate charging current

• Automatic termination upon charging completion

• Reverse polarity protection and short circuit protection

• Over-discharged battery activation

• Li-ion battery restoration

• Overtime charging protection

• Automatic detection of battery internal resistance and display of battery health

• Made from durable and re-retardant PC materials

• Optimal heat dissipation design

• Certied by RoHS, CE, FCC and CEC

• Insured worldwide by Ping An Insurance (Group) Company of China, Ltd.

USB Charging Cable

Input: DC 5V/2A 9V/2A

18W (MAX)

Output: 4.35V±1% / 4.2V±1% / 3.7V±1% / 1.48V±1%

QC Mode: 1,500mA*1 (MAX), 1,500mA*2 (MAX), 750mA*4 (MAX)

Standard Mode: 1,500mA*1 (MAX), 1,000mA*2 (MAX), 500mA*4 (MAX)

Compatible with:

IMR/Li-ion/LiFePO4: 10440, 14500, 14650, 16500, 16340(RCR123), 16650,

17350, 17500, 17650, 17670, 17700, 18350, 18490,

18500, 18650, 18700, 20700, 21700, 22500, 22650,

25500, 26500, 26650, 26700

Ni-MH/Ni-Cd: AA, AAA, AAAA, C, D

Dimensions: 159mm×107mm×41mm (6.26”×4.21”×1.61”)

Weight: 232.8g (8.21oz) (Charging cable not included)

Produktspecifikationer

Varumärke:	Nitecore
Kategori:	Batteriladdare
Modell:	UM4
Färg på produkten:	Rood
Vikt:	8200 g
Bredd:	249 mm
Djup:	290 mm
Höjd:	295 mm
Förpackningens bredd:	320 mm
Djuppackning:	275 mm
Förpackningshöjd:	335 mm
Kraftkälla:	AC
Tillgångar:	380 W
Typ av strömkälla:	AC
AC-ingångsspänning:	230 V
AC-ingångsfrekvens:	50 Hz
