• Intelligent PIR detection system
• Detection of ambient temperature and illuminance for automatic sensitivity
management
• Advanced detection algorithm
• Three dual pyro-elements with patented Double Conductive Shielding for
main area
• Built-in creep zone detector (Double dual pyro-elements)
• Anti-vandalism functions
Anti-rotation function with accelerometer
Anti-masking function with photo-beam
Reinforced polycarbonate housing
• Max. 4m (13ft.) installation height
• Independent sensitivity selector for creep/near/far areas
• Adjustable alarm interval time
• BS8418 Compliant - U.K.
• POE compliant
• IP sensors integrated with major VMS providers*
*The SIP-3020/5-IP, SIP-4010/5-IP SIP-404/5-IP are currently fully integrated
with Milestone XProtect® and the REDWALL event code is integrated with
Genetec Security Center. Please check the latest status by consulting the
integration list on our website.
FEATURES
020/5-IP SIP-4010/5-IP and SIP-404/5-IP are outdoor,
ge, IP infrared sensors which are POE compliant and
eamlessly with major Video Management Systems (VMS)
These sensors are specically designed to trigger video
on systems and PTZ cameras; and make the visual
for remote video monitoring, easier and more accurate.
020/5-IP, SIP-4010/5-IP and SIP-404/5-IP cover a detection
pectively 30x20m, 40x10m, and 40x4m; and they all feature
al PIR detector with an independent alarm output at the
he unit to cover the creep zone (max 6x9m area).
020/5-IP, SI-4010/5-IP and SIP-404/5-IP provide a total of 3
uts, 2 independent outputs for far and near area of the main
nd an additional one for the creep zone. Multiple outputs are
for activating video transmission systems, controlling PTZ
ving a better view of the intruders across pre-set areas.
020/5-IP, SIP-4010/5-IP SIP-404/5-IP are automatically
he sensitivity to the environment such as temperature
ance conditions to minimise false alarms. They are also
with anti-vandalism features.
SIP-3020/5-IP SIP-4010/5-IP SIP-404/5-IP
Synthesized Intelligent IP outdoor PIR detectors with creep zone
Model SIP-3020/5-IP SIP-4010/5-IP SIP-404/5-IP
Detection method Passive infrared
Coverage (main area) 30 x 20 m (100 x 65 ft.) 40 x 10 m (130 x 33 ft.) 40 x 4 m (130 x 13ft)
Coverage (creep zone) 3x 5m (10 x 16ft.) installed at 2.3m (7.6ft.) height, 6 x 9m (20 x 30ft.) installed at 4m (13ft.) height, detection angle adjustable horizontally
Power supply PoE * (IEEE802.3af/at compliant)
Current draw 40mA max, 75mA, 415mA max with optional heating unit
Mounting height 2.3 to 4 m (7.6 to 13 ft.)
Sensitivity selector Far: SH/H/M/L Near: SH/H/M/L Creep zone: SH/H/M/L
Detection logic selector AND / OR
Alarm output (main area) Near area Redwall event code (UDP/TCP) Far area Redwall event Code (UDP/TCP)
Alarm output (creep zone) Redwall event code (UDP/TCP)
Alarm interval period Off/15, 30, 60 sec
Alarm period Approx. 2 sec
Warm-up period Approx. 60 sec
Operating temperature -25 to +60 C, -40 to +60 C with optional heating unit (-13 to +140 F, -40 to +140 F with optional heating unit)
If the heater is used, it should be external 22-26V AC (not POE)
IP rating Main unit:IP65 / Chassis:IP55
Dimensions (H x W x D) 248 x 102 x 266 mm (9.8 x 4.0 x 11.4 in.)
Weight 1.9 kg
Supported protocols IPv4, ARP, UDP, TCP, ICMP, HTTP
Function setting Use web browser
• Specications and design are subject to change without prior notice.
SPECIFICATIONS
SIP-AT - SIP Adjustment tools (include AVF-1 Area view nder and AWT-3 Audible walk tester)
SIP-HU - Heating Unit (When the SIP-HU is used, the power for SIP series should be 22-26VAC.)
SIP-MINI HOOD - Sun/Snow shield
OPTIONS
SYSTEM DIAGRAM
SIP-3020/5-IP SIP-4010/5-IP
DETECTION AREAS
Redwall IP detectors communicate with major video
management software by Redwall Event Code protocol via
Power-over-Ethernet. Alarm signal information generated
by Redwall IP detectors can be used to control IP camera
for automatic tracking of intruder’s movement, or alarm
management on video management software.
SIP-404/5-IP
